WP series
 | |
| It is widely used for window&split air condition,car air-condition Specfication: 1)designed temperature range:0~40 2)on-off temperature difference:2~5 3)adjustable temperature range:max16 4)rated at 20A/250V 50/60HZ 5)the center of installing hole:55±0.25mm or 33±0.25mm 6)operating life:no less than 100,000times 7)manufactured on customer request |
| Type | Action Temperature （℃ ） | Max Temp of Sensor （℃ ） | Capillary tube (mm) | Puffing type | ||||||
| Warm Point | Cold Point | P.D | ||||||||
| ON | OFF | DIFF | ON | OFF | DIFF | OFF | ||||
| WP17C-L | (32.3） | 30 ± 2 | 2 ～ 4 | ’（19.8） | 17 ± 1.5 | 2 ～ 4 | < 8 | 80 | 360 | Gas |
| WP14C-L | ‘（32.5） | 30 ± 2 | 1.5 ～ 3.5 | ‘（17） | 14 ± 1.5 | 2.5 ～ 4 | < 8 | 80 | 433 | Gas |
| WPF16A-L | --- | 30 ± 2 | 2 ～ 4 | --- | 16 ± 1.5 | 2 ～ 4 | --- | 55 | 290 | Carbon |
| WP12B-L | ’（27.3） | 24.4 ± 2 | --- | ’（15） | 12 ± 1.5 | 3 ± 1.5 | --- | 55 | 235 | Carbon |
| WP15Y-LR | ‘（32.5） | 30 ± 2.5 | 2 ～ 4 | 、‘（18） | 15 ± 1.5 | 2 ～ 4 | < 8 | 55 | 250 | Carbon |
